    AISI 52100 Cold Drawn Hardened Alloy Steel Round Bar High Mechanical For Bearing

    Ask Lasest Price
    Brand Name : VANFORGE
    Certification : ISO9001, ISO10012, ISO14001, OHSAS18001, ABS, BV, DNV, Lloyd, NK
    Payment Terms : L/C, T/T
    Supply Ability : 5000 metric tons per month
    Delivery Time : 60 days
    Price : Negotiable
    • Product Details
    • Company Profile

    AISI 52100 Cold Drawn Hardened Alloy Steel Round Bar High Mechanical For Bearing

    AISI/ASTM 52100 bearing steel is a high carbon, chromium containing low alloy steel that is through hardening and noted in particular for use as bearings.

    52100 bearing steel is one kind of special steel with features of high wear resistance and rolling fatigue strength. High-carbon chromium bearing steel, engineering steel and some types of stainless steel and heat resistant steel are used as materials of bearings and for other purposes.

    Advantages of Chrome Bearing Steel 52100:
    Superior hardness, 60-67 on Rockwell hardness scale at room temperature
    High carbon chrome alloy steel
    Operates continually at temperatures up to 120°C
    Used to produce precision ball bearings and roller bearings
    Cost-effective
    Long working life

    1. Supply Range of ASTM 52100 Bearing Steel
    AISI 52100 Steel Round Bar: diameter 8mm – 800mm
    Process: Cold drawn, hot rolled, forged etc.
    Surface Finish: black, rough machined, turned, polished or as per given requirements.

    2. Relevant Steel Specification of ASTM 52100 Bearing Steel

    CountryUSAGermanyJapanBritish
    StandardASTM A295DIN 17230JIS G4805BS 970
    Grade52100100Cr6/1.3505SUJ2535A99/EN31


    3. Chemical compositions of 52100 bearing steel and equivalents

    StandardGradeCMnPSSiNiCrCuMo
    ASTM A295521000.93-1.050.25-0.450.0250.0150.15-0.350.251.35-1.600.300.10
    DIN 17230100Cr6/1.35050.90-1.050.25-0.450.0300.0250.15-0.350.301.35-1.650.30
    JIS G4805SUJ20.95-1.100.500.0250.0250.15-0.351.30-1.60--
    BS 970535A99/EN310.95-1.100.40-0.70--0.10-0.35-1.20-1.60--


    4. Mechanical Properties of ASTM A295 52100 Bearing Steel

    PropertiesMetricImperial
    Bulk modulus (typical for steel)140 GPa20300 ksi
    Shear modulus (typical for steel)80 GPa11600 ksi
    Elastic modulus190-210 GPa27557-30458 ksi
    Poisson’s ratio0.27-0.300.27-0.30
    Hardness, Brinell--
    Hardness, Knoop (converted from Rockwell C hardness)875875
    Hardness, Rockwell C (quenched in oil from 150°C tempered)6262
    Hardness, Rockwell C (quenched in water from 150°C tempered)6464
    Hardness, Rockwell C (quenched in oil)6464
    Hardness, Rockwell C (quenched in water)6666
    Hardness, Vickers (converted from Rockwell C hardness)84848484
    Machinability (spheroidized annealed and cold drawn. Based on 100 machinability for AISI 1212 steel)4040


    52100 Steel Physical Properties

    PropertiesMetricImperial
    Density7.81 g/cm30.282 lb/in³
    Melting point1424°C2595°F


    52100 Alloy Steel Thermal Properties

    PropertiesMetricImperial
    Thermal expansion co-efficient (@ 23-280°C/73.4- 36°F, annealed)11.9 µm/m°C6.61 µin/in°F
    Thermal conductivity (typical steel)46.6 W/mK323 BTU in/hr.ft².°F


    5. Forging of A295 52100 Bearing Steel
    AISI 52100 alloy steel is forged at 927 to 1205°C, and should not be forged below 925ºC. A post-forge equalization treatment is recommended at 745ºC for 4-6 hours followed by air cooling for SAE/AISI 52100 steel.

    6. Heat Treatment for ASTM 52100 Bearing Steel
    ASTM/AISI 52100 alloy bearing steel is heated at 816°C followed by quenching in oil. Before performing this process, it is subjected to normalizing heat treatment at 872°C followed by slowly cooling in order to reduce the machining stress.

    Hot Working
    AISI 52100 bearing steels alloy can be hot worked at 205 to 538°C.

    Cold Working
    AISI 52100 bearing steel can be cold worked using conventional techniques in the annealed or normalized conditions.

    Annealing
    For spheroidize annealing, the following isothermal anneal is recommended:

    1500ºF (815ºC) for 3 hours
    1350ºF (735ºC) for 4 hours
    1250ºF (675ºC) for 3 hours
    Slow cool to 1000ºF (540ºC) then air cool.

    Quenching
    AISI 52100 alloy bearing steel could be hardened by quenching in water from 801-829 degree or quench in oil from 816-842 degree.

    Tempering
    Temper to desired hardness as indicated by tempering curves after water or oil quench.

    7. Applications of 52100 Bearing Steel
    Alloy steel 52100 grade bearing steel is mainly used for the manufacture of aircraft bearings and other highly stressed parts. This steel grade 52100 steel is preferably vacuum arc re-melted to give optimum performance.

    Typical applications: Bearing Manufacture, CV joints, ball screws, gauges, knife etc.

    Product size range
    Diameter: 40mm - 150mm
    Length: on request
